Research

In this research direction, we focused on two different applications:

Construction

The two robot arms will remain to support the frame while the other two arms secure the frame to the wall by bolting it in place for added stability. To simplify the task, the wooden beams will be prepositioned in the grip of the robotic arms, eliminating the need to control the arms to reach and grasp the beams.
Coordination control will be necessary for the supernumerary arms to reposition the beam in an ergonomic posture, facilitating the operator’s task of unpacking as their natural arms move along the beam to extract the cover. Moreover, the supernumerary arms must counterbalance the interaction forces produced by the operator’s natural arms on the beam.

Laparoscopy

This project tackles the design of a 4-arms system with application to laparoscopic surgery. Currently, this task is performed by at least two people: the surgeon and one assistant who is manipulating the endoscope and the retractor. The envisioned 4-arms system would enable the surgeon to control all four instruments. This may increase synchrony in the movements and avoid ambiguity arising from miscommunication.

Conventional Laparoscopy vs The Envisioned Scenario, The Supernumerary Robotic Assisted Laparoscopy

This project participates in a novel research area in human-robot interaction that develops supernumerary devices to augment human natural dexterity. Our 4-arms system will consist of two supplementary robotic arms driven by the user’s feet. In this way simultaneous coordinated control of four arms by a single user will be attempted for a complex manipulation task, for the first time to our knowledge. To ease the control of the two supplementary arms, we will provide the robotic arms with partial autonomy. Low-level control for forces at contact and for precise trajectory following will be done autonomously, while the direction of movement will be initiated by the user. To provide this autonomy, we will use learning approaches to model the expected task features in force and task domains. Additionally, we will study how dyads of surgeons perform this task to model the typical dynamics of coordination in the dyad. This will inform the design of proactive robotic controllers to better anticipate the user’s requests. The design of the system will be informed all along through user studies conducted with surgeons and using a simulated surgical environment.
